Dublin Stall Front with Feed Door
Dublin stall fronts are an excellent portable or permanent horse stall solution. They are constructed of hot-dip galvanized steel for rust protection and have hidden interior welds to avoid burrs. Extremely versatile and solid for open span barns. Add a feed door and you can feed both hay and grain from your aisle. A portable style stall that is definitely a cut above the rest. A great solution for open span barns, arena stalls and outdoor covered – temporary to permeant stalling.
Compatibility: Dublin Partitions
[yith_wcwl_add_to_wishlist]
Dublin stall fronts are an excellent portable or permanent horse stall solution. This horse stall allows for good ventilation and socialization, has no edges for your horse to chew, is easy to install, and has customization options available for feed doors and gates. One touch tear drop track and trolley, rather than round, is self cleaning and self aligning. The added Feed Door allows you to feed both hay and grain from your aisle. Dublin horse stalls are constructed of hot-dip galvanized steel, 14-gauge frame and features hidden interior welds with better rust proofing.
Length: 10′ or 12′ (Custom sizes available upon request.)
Finish: Hot-Dip Galvanized
Channel Gauge: 14-gauge
Frame Gauge: 2″ x 2″ 14-gauge
Door Gauge: 1-3/4″ x 1-3/4″ 14-gauge
Bar Gauge: 16-gauge
Full Grill Door Bottom Bars Gauge: 14-gauge
Bar Spacing: 3-1/4º”
Bar Diameter: 7/8″
Bar Height: 33″
Door Width: 51-1/2″
Door Opening Width (Standard): 48″
Door Height: 80-3/8″
Floor to Top of Header: Top of Front is 84″, Top of Front with Track Piece =is 85-3/8″
Floor to Bottom of Bars: 48-5/8″
Latch Type: Up Latch
Post: Door Stop (*Varies by layout.)
Guide: Door Stay
Track: 8′ Premium Track
Wood Direction: Vertical *Note: You supply the wood to save on freight costs.
Warranty: 1-Year Warranty on Workmanship.
Made in the USA.
Below are links to installation instructions and literature regarding Dublin horse stalls. They are in a PDF format, which you can save and print for future reference:
Dublin Stall Installation Instructions
Portable Panel Stall Installation Instructions – Square Track System
The Appearance of Hot-Dip Galvanized Coating
Installation: This is a freestanding horse stall system; no support posts are required for this installation. Connect the stall panels with stall connectors, which are sold separately and can be found here. *Note: Wood lumber is not included; we recommend tongue and groove wood for all of our horse stall systems.
