Harris Area Light Lumen Select ALLP1
The ALLP1 provides multiple combinations of options to maximize labor and energy savings. The ALLP1 Area Light provides uniform distribution for area and site lighting in retail, commercial, and residential applications including driveways and parking areas. Two fixture knockouts for easy access to adjust wattage, CCT, and install sensors.
[yith_wcwl_add_to_wishlist]
The ALLP1 is a cost-effective area light designed to offer optimal flexibility to the customer. The ALLP1 provides multiple combinations of options to maximize labor and energy savings. The ALLP1 Area Light provides uniform distribution for area and site lighting in retail, commercial, and residential applications including driveways and parking areas. Two fixture knockouts for easy access to adjust wattage, CCT, and install sensors. Pre-wired sensor receptacle allows for easy screw-in installation. No in-field sensor wiring required! Select from 5 mounting options!
Select from the following Lumen package of UNIVERSAL VOLTAGE with either Selectable CCT of 399k/4000/5000K:
12,000 Lumens Package of 81 watts at 277 volts lights
14,000 Lumens Package of 100 watts at 277 volts lights
15,000 Lumens Package of 105 watts at 277 volts lights
20,000 Lumens Package of 146 watts at 277 volts lights
24,000 Lumens Package of 168 watts at 277 volts lights
28,000 Lumens Package of 201 watts at 277 volts lights
32,000 Lumens Package of 238 watts at 277 volts lights
36,000 Lumens Package of 268 watts at 277 volts lights
42,000 Lumens Package of 304 watts at 277 volts lights
Select from the following Lumen package of HIGH MULIT-VOLT with either Selectable CCT of 399k/4000/5000K:
12,000 Lumens Package of 80 watts at 277-480 volts lights
14,000 Lumens Package of 100 watts at 277-480 volts lights
15,000 Lumens Package of 105 watts at 277-480 volts lights
20,000 Lumens Package of 145 watts at 277-480 volts lights
24,000 Lumens Package of 170 watts at 277-480 volts lights
28,000 Lumens Package of 200 watts at 277-480 volts lights
32,000 Lumens Package of 230 watts at 277-480 volts lights
36,000 Lumens Package of 260 watts at 277-480 volts lights
42,000 Lumens Package of 300 watts at 277-480 volts lights
CALL FOR PRICING
Type II, III, IV, and Type V light distributions.
Field selectable lumens provide a late point adjustment at the installation site 12,000 to 42,000 lumens.
Nine lumen packages.
Tool-less field installable lens kit for Type II, III, IV, and Type V for each upgrade of light distribution in the field.
Precision engineered lens made of optical grade polycarbonate for maximum light intensity.
Anti-corrosion stainless steel hardware.
Heavy duty die-cast aluminum housing with external heat-sink for optimal thermal management.
Fixture comes standard in bronze. Field selectable CCT between 3000K, 4000K or 5000K.
Minimum 80 CRI. Efficacy up to 158 LPW
