Premium Track Door Hardware Kit
The Premium track door hardware kit has all components needed to hang an Essex or Oxford horse stall door, excluding the 8′ Premium track and lifting rod.
Your Price: $240.47 – $366.83
[yith_wcwl_add_to_wishlist]
The Premium track door hardware kit has all components needed to hang an Essex or Oxford horse stall door, excluding the 8′ Premium track and lifting rod. This kit is assembled with the horse owner in mind. This Premium track door hardware kit is compatible with the Essex and Oxford horse stall systems.
Not Included:Â
- 1 – 8′ Premium Track
- 1 – Lifting Rod
Which lifting rod fits your needs?
[47-1/8″] “Long” Lifting Rods Compatibility:
- Grill Top Doors [A]
- V-Doors [B]
[43-1/4″] “Short” Lifting Rods Compatibility:Â
- Full Grill Doors [G]
- Full Grill V-Doors [H]
- Grill Top Mesh Bottom Doors [J]
- Mesh Bottom V-Doors [K]
- Full Mesh Doors [I]
Finish: Galvanized or Powder-Coated Black
Compatibility: Essex and Oxford horse stalls
Not Included: 8′ Premium Track & Lifting Rod
Includes:Â
- 1 – Door Top Latch System Hardware Kit (door latch handle and self-latching system hardware)
- 1 – Stay Roller
- 3 – 1/4″ x 1-1/2″ Phillips Pan Head Stay Roller Screws
- 1 – Post Bumper
- 2 – 5/16″ x 1-1/2″ Hex Head Lag Screws
- 7 – Premium Track 1″ Extended Top Mount Brackets
- 21 – #10 x 1-1/2″ Phillips Pan Head Premium Track Bracket Screws
- 2 – Premium Track Trolleys
- 2 – Premium Track 1/2″ x 9″ Offset Trolley Bolt & Nuts
- 2 – Premium Track End Caps
- 2 – 1/4″ x 4″ Hex Head Lag Screws
- 2 – 1/4″ Flat Washers
- 1 – 3/8″ x 3-1/2″ Hex Head Bolt
- 1 – 3/8″ USS Flat Washer
- 1 – 3/8″ Lock Nut
Click here to access the Essex horse stalls’ installation instructions PDF, which you can save or print for reference.
Click here to access the Oxford horse stalls’ installation instructions PDF, which you can save or print for reference.
