Essex Feed Opening Plate
Maintain your barn’s feeding efficiency with the Essex Replacement Feed Opening Plate. Feed your horses safely from the aisle without breaking the budget using this direct replacement part.
Compatibility: Essex Stalls
Proudly Made in the USA. No imported horse stalls—just American craftsmanship you can trust.
Ensure your daily feeding routine remains efficient with the Essex Replacement Feed Opening Plate. Essex feed openings provide an economical, highly effective way to feed your horses directly from the barn aisle. When you need to replace a damaged or worn plate, this direct replacement part restores your stall front’s functionality quickly and easily.
By feeding from the outside of the stall, you eliminate the need to open doors and navigate around hungry horses, significantly speeding up morning and evening chores. Keep your facility running smoothly and maintain a safe environment for both your staff and your horses.
Key Benefits:
-
Restore Functionality: Replace worn or missing plates to keep your feed opening operating perfectly.
-
Maximize Efficiency: Distribute grain quickly from the aisle to save valuable time and effort.
-
Enhance Safety: Keep farmhands securely outside the stall during busy mealtimes.
-
Cost-Effective Maintenance: Fix your existing setup economically without replacing the entire system. (Note: Installation hardware sold separately).
Quantity: Sold Individually (1, Essex feed opening plate; hardware is not included)
Finish: Pre-Galv
Height: 12″
Opening Height: Varies (We recommend 9″)
Width: 12″
Opening Width: 11″
Depth: 1.5″
Compatibility: Essex Stalls
Shipping: This item ships via UPS.
*Note: Hardware is not included. You have to cut your bars down to install the feed opening plate.
Decide where you want the feed opening to be located. Cut two of your 3/4″ horse stall grill bars to the desired length (bars cut to 22″ will give you approximately a 12″ opening). Slide the feed opening plate over the two outer bars of the opening and let it rest on the bottom grill channel. Insert the two cut bars into the top grill channel and slide the feed opening up until it is tight. Lastly, use the 8-18 x 3/4″ hex hard self-drilling screws to hold the feed opening plate in place through the holes in the feed opening plate.
Below is a link to the installation instructions for our Essex standard horse stalls in a PDF format, which you can save and print for future reference:
