Cambridge Stall Front with Full Grill V-Door
Cambridge stall fronts are fully welded for strength and longevity. The product features either a beautiful, sleek black powder coat or a durable hot-dip galvanized finish. The product features safer interior welded grillwork bars with closer bar spacing, a fully welded door frame with a welded grill top, and numerous customization options. The one-touch teardrop track and trolley system offers smooth door operation for years. Faster and easier installation makes Cambridge a favorite builder’s choice.
[yith_wcwl_add_to_wishlist]
Cambridge stall fronts are fully welded with the addition of a full grill door and V-door opening. The product features a beautiful sleek black powder coat or a durable hot-dip galvanized finish. The interior features safer welded grillwork bars with closer bar spacing, fully welded doors, and many customization options. The one-touch teardrop track and trolley, as opposed to a round design, is self-cleaning and self-aligning. The unique profile has a square side, allowing the track to be firmly and squarely mounted. Rugged nylon wheels have sealed and greased bearings to ensure smooth operation for years. All hardware is included; you supply the wood to save on freight costs.
Length: 10′ or 12′ (*Custom sizes available upon request.)
Finish: Hot-Dip Galvanized or Powder-Coated Black
*RAMM has the industry’s premier hot-dip galvanization for horse stalls.
Channel Gauge: 14-gauge
Full Grill Door Bottom Bar Gauge: 14-gauge
Bar Gauge: 16-gauge
Bar Spacing: 3¼”
Bar Diameter: ⅞”
Bar Height (Inside-to-Inside): 33″
Door Width: 51½”
Door Opening (Standard): 48″
Door Height (Finished): 81⅜”
Floor to Top of Header: 90¼”
Floor to Bottom of Bars: 47¾”
Latch Type: Up Latch
Post: Post Bumper
Guide: Stay Roller
Track: 8′ Premium Track
Wood Direction: Horizontal (*Note: Wood lumber is not included with the kit.)
Kit Includes:
- 1- Stall Door Kit
- 1 – Grillwork Section
- 1 – 8′ Premium Track
- 1 – Premium Track Door Hardware Kit (includes: track brackets, trolleys, trolley bolts, stay roller, post bumper, and hardware)
- Stainless Steel Receiver
- Spring-Loaded Bar Latch
- Stall Screws
Warranty: 1-Year Warranty on Workmanship.
*Note: Lumber is not included to save freight. We recommend tongue and groove wood for all RAMM horse stall systems. Wood count in the installation instructions are estimated and based on 2 x 6” tongue and groove boards as wood supplier measurements can vary.
Made in the USA.
